48V to 24V DC Step dc voltage converter 2A, 3A, 5A, 6A,10A,15A,20A,25A,30A,40A,50A,60A,80A,100A,120A,125A
Input Voltage: DC30V-60V Output voltage: DC24V Output current : 2A, 3A, 5A, 6A,10A,15A,20A,25A,30A,40A,50A,60A,80A,100A,120A,125A Design: Non Isolated (We provide customized for different kinds of DC-DC solutions, if you can not find the right specification to meet your requirement. Contact us now! It will not cost you one cent when you ask us anything, but it may be a chance for both of us)
- Input Voltage: DC 30V-60V / Output Parameters: DC24V, 2A, 3A, 5A, 6A,10A,15A,20A,25A,30A,40A,50A,60A,80A,100A,120A,125A
- High conversion efficiency: Synchronous Rectification Technology, multiple intelligent protection functions, conversion efficiency of up to 93%, good stability, and easy installation.
- Protection: High-quality aluminum shell, Fast heat dissipation. Built-in Overload, Overcurrent, Overvoltage, Overtemperature, and Short circuit protection, IP67 waterproof and shockproof, and can return to normal state during operation.
- Application: Widely used in golf carts, photovoltaic, electric power, monitoring systems, automobiles, electric bicycles motorcycle scooters, LED, instruments, etc
- Precision manufacturing, excellent performance, one-year warranty, worry-free after-sales, and rapid response.
- keywords: dc voltage converter
|
Input Voltage VDC Range |
Output Volts VDC |
DC Output Current AMP |
Max Power WATT |
| 30-60VDC | 24VDC | 1A | 24W |
| 30-60VDC | 24VDC | 1A | 24W |
| 30-60VDC | 24VDC | 2A | 48W |
| 30-60VDC | 24VDC | 2A | 48W |
| 30-60VDC | 24VDC | 3A | 72W |
| 30-60VDC | 24VDC | 3A | 72W |
| 30-60VDC | 24VDC | 4A | 96W |
| 30-60VDC | 24VDC | 4A | 96W |
| 30-60VDC | 24VDC | 5A | 120W |
| 30-60VDC | 24VDC | 5A | 120W |
| 30-60VDC | 24VDC | 5A | 120W |
| 30-60VDC | 24VDC | 6A | 144W |
| 30-60VDC | 24VDC | 6A | 144W |
| 30-60VDC | 24VDC | 6A | 144W |
| 30-60VDC | 24VDC | 10A | 240W |
| 30-60VDC | 24VDC | 15A | 384W |
| 30-60VDC | 24VDC | 20A | 480W |
| 30-60VDC | 24VDC | 30A | 720W |
| 30-60VDC | 24VDC | 40A | 960W |
| 30-60VDC | 24VDC | 50A | 1200W |
| 30-60VDC | 24VDC | 60A | 1440W |
| 30-60VDC | 24VDC | 80A | 1920W |
| 30-60VDC | 24VDC | 100A | 2400W |
| 30-60VDC | 24VDC | 125A | 3000W |
